# NUKEPROOF PART # QTY
1 Front Triangle 1
2 Seat Stay 1
3 Chain Stay 1
4 Swing Link 1
5 6802 Llu Max 4
6 6901 Llu Max 2
7 6902 Llu Max 5
8 Main Pivot Axle Collett Washer 1
9 Horst Link Washer 4
10 Lower Swing Link Lock Ring 2
11 None-Drive Motor Cover Bolt 3
12 Motor Mount Bolt 4
13 Accessory Mount Nut 2
14 Accessory Mount Screw 2
15 Lower Motor Mount Bolt None-Drive 1
16 Lower Motor Mount Bolt Drive-Side 1
17 Motor Bolt 35mm 3
18 Motor Bolt 46mm 2
19 Shock Bolt 2
20 Horst Link Pivot Axle 2
21 Horst Link Bolt 2
22 Lower Motor Mount 1
23 Upper Motor Mount 1
24 Main Pivot Bearing Spacer 1
25 Upper Battery Bolts 2
26 Lower Battery Bolt 1
27 Lower Battery Bolt Cap 1
28 Chain Guide Mount 1
29 Chain Guide Flip Chip 1
30 Brake Hose Grommet 1
31 Derailleur Cable Grommet 1
32 Main Pivot Axle 1
33 Motor Protector 1
34 Motor Cradle Drive-Side Cover 1
35 None-Drive Motor Cover 1
36 Motor Bolt Spacer Round 4
37 Motor Bolt Spacer Square 1
38 Lower Swing Link Bolt 2
39 Non-Drive Side Seat Stay Chip 1
40 Drive Side Seat Stay Chip 1
41 Lower Swing Link Washer 2
42 Shock Bolt Nut 1
43 Main Pivot Washer 2
44 Brake Mount 1
45 Upper Swing Link Pivot Spacer 2
46 Swing Link Pivot Bolt 2
47 Swing Link Pivot Axle 1
48 Brake Mount Bolts 2
49 Horst Link Bearing Spacer 2
50 Motor Bolt Nut 2
51 Headtube Cable Bungs 4
52 Chain Guide 1
53 Chain Guide Bolt 1
54 Chain Guide Washer 1
55 Lower Battery Bolt Cap O-Ring 1
A Cs Protection 1
B Ss Protection 1
C Dt Protection 1
exploded parts
