Nukeproof MEGAWATT - Spare Parts Kits

MEGAWATT CARBON BIKE MANUAL | 5 3
SPARE PARTS KITS
KIT NAME DRAWING # PART #
PART NAME
QTY
Megawatt Carbon Lower Swing Link Kit Drive Side
38 NPB9-RBT
Lower Swing Link Bolt
1
10 IR-28
Lower Swing Link Lock Ring
1
41 NPC-WS27-15-4T
Lower Swing Link Washer
1
40 NPB9-SPT-R
Drive Side Seat Stay Chip
1
Megawatt Carbon Lower Swing Link Kit Non-Drive Side
38 NPB9-RBT
Lower Swing Link Bolt
1
10 IR-28
Lower Swing Link Lock Ring
1
41 NPC-WS27-15-4T
Lower Swing Link Washer
1
39 NPB9-SPT-L
Non-Drive Side Seat Stay Chip
1
Megawatt Carbon Swing Link 4 NPB9B-LK
Swing Link
1
Megawatt Carbon Bearing Kit
5 6802 LLU MAX
6802 LLU MAX / 6802V-2RS
4
6 6901 LLU MAX
6901 LLU MAX/ 6901V-2RS
2
7 6902 LLU MAX
6902 LLU MAX/ 6902V-2RS
5
Megawatt Carbon Main Pivot Kit
32 NPB9-LAX
Main Pivot Axle
1
8 AFDC-CWS
Main Pivot Axle Collett Washer
1
43 NTR-BWS
Main Pivot Washer
2
24 NPB9-BSP
Main Pivot Bearing Spacer
1
Megawatt Carbon Battery Bolt Kit
26 NPB9-BTM10X24.5L
Lower Battery Bolt
1
25 NPB9-BTBT
Upper Battery Bolt
2
27 NPB9-BTSN
Battery Door Cap
1
55 O-Ring 18x1.5
Lower Battery Bolt Cap O-Ring
1
Megawatt Carbon Motor Protector Kit
13 M5X2.7L
Accessory Mount Nut
2
14 M5X10L-R11Q
Accessory Mount Screw
2
33 NPB9-MOCV-A
Motor Protector
1
Megawatt Carbon None-Drive Motor Cover
11 M4X10L-M11Q
None-Drive Motor Cover Bolt
3
35 NPB9-MOCV-C
None-Drive Motor Cover
1
Megawatt Carbon Upper Motor Mount Kit
12 M4X12L-R11Q
Motor Mount Bolt
2
23 NPB9-BGM
Upper Motor Mount
1
Megawatt Carbon Lower Motor Mount Kit
12 NPB9-BGM
Motor Mount Bolt
2
15 M8X25L-R11Q
Lower Motor Mount Bolt None-Drive
1
16 MB-T40-30L
Lower Motor Mount Bolt Drive-Side
1
22 NPB9-AR
Lower Motor Mount
1
Megawatt Carbon Motor Cradle Drive-Side Cover 34 NPB9-MOCV-B
Motor Cradle Drive-Side Cover
1
Megawatt Carbon Motor Bolt 35mm 17 MB-T40-35L
Motor Bolt 35mm
1
Megawatt Carbon Motor Bolt 46mm 18 MB-T40-46L
Motor Bolt 46mm
1
Megawatt Carbon Motor Bolt Spacer Round 36 NPB9-MOW
Motor Bolt Spacer Round
1
Megawatt Carbon Motor Bolt Spacer Square 37 NPB9-MOWC
Motor Bolt Spacer Square
1
Megawatt Carbon Motor Bolt Nut 50 NPB9-BTMO
Motor Bolt Nut
2
Megawatt Carbon Chain Guide Kit
28 NPB9-CG
Chain Guide Mount
1
29 NPB9-CG-A
Chain Guide Flip Chip
1
Megawatt Carbon Grommet Kit
30 VBFB-LMCG
Derailleur Cable Grommet
1
31 VBFB-RMCG
Brake Hose Grommet
1
51 VLD-1442
Headtube Cable Bungs
4
Megawatt Carbon Chain Stay Protection A VLF-C-1584e
Chain Stay Protection
1
Megawatt Carbon Seat Stay Protection B VLF-C-1585e
Seat Stay Protection
1
Megawatt Carbon Down Tube Protection C VLF-C-1605e
Down Tube Protection
1
