MEGAWATT CARBON BIKE MANUAL | 5 6
UK BRAKE & DROPPER CABLE ROUTING GUIDE*
ENTRANCE PORT POSITION
1
2
3
4
1 - Rear brake routing
2 - AXS display unit wire routing
3 - Dropper post routing
4 - Rear derailleur routing
*Please note bikes supplied with wireless dropper post and derailleurs, routing for reference proposes if components
changed to cabled items
