MEGAWATT CARBON BIKE MANUAL | 5 7
DRAWING # PART
22 LOWER MOTOR MOUNT
23 UPPER MOTOR MOUNT
36 MOTOR BOLT SPACER ROUND
37 MOTOR BOLT SPACER SQUARE
50 MOTOR BOLT NUT
15 LOWER MOTOR MOUNT BOLT NON-DRIVE SIDE 25MM
16 LOWER MOTOR MOUNT BOLT DRIVE-SIDE 30MM
17 MOTOR BOLT 35MM
18 MOTOR BOLT 46MM
