MEGAWATT CARBON BIKE MANUAL | 6
SECTION 2 – MAIL ORDER ASSEMBLY AND INITIAL SET-UP
This section details how to get your bike ready for setting up and riding out of the box, this will be relevant for mail order
bikes, generally the following will be done already if purchased and collected through a local authorised Nukeproof dealer.
Do not turn on your bike at this point.
FIT BARS
1. Unscrew face plate bolts from stem with a 4mm Hex
Key, remove stem face plate and bolts, set aside safely
for installing later.
2. Place bars to stem, using the set-up lines to position
the bars centrally. Ensure brake lines are not tangled at
this point.
3. Tighten the face plate bolts to the stem with a 4mm
Hex Key, start with the top bolts and move to the bottom
bolts. Ensure bolt torque is evenly spread around all
four bolts before fully tightening. Reference the torque
details on the stem.
4. You can adjust the roll of the bars back or forward at
this point to your personal preference. Ensure the bars
are still centered when adjusting and use the markings
on the bars to help. This is a good point to adjust position
of PODS and brakes levers.
