5.2.1.5 Input of Programme Origin Eccentricity Values
Eccentricity values (DAT3 for milling machines fitted with an index table) are entered via the keyboard. Shift DAT3 must
be entered for both axes concerned by index table rotation. After entry, these two axes are marked *.
Requirements
No mode being executed. If a mode is being executed, selection of this mode is only taken into account after an
interruptible block.
Actions
Select the origin shift mode (See 5.2.1.1).
Display the dialogue line for DAT3 input. ☞
SHIFTS
SHIFTS
Display of dialogue line for "DAT3: ❚".
Enter "[axis 1] [value of DAT3] [axis 2] [value of DAT3]". ☞
Transfer of the entered shifts to the DAT3 values which are then displayed on the screen.
5.2.1.6 Input of Scaling Factor
A scaling factor (SCALE) can be entered via the keyboard to modify the dimensions of the parts to be machined.
Requirements
No mode being executed. If a mode is being executed, selection of this mode is only taken into account after an
interruptible block.
Actions
Select the origin shift mode (See 5.2.1.1).
Display the dialogue line to input the scaling factor by pressing (three times). ☞
SHIFTS
Display of "SCALE (E..) ❚" in the dialogue line.
Enter "E [value of scaling factor]". ☞
The scaling factor is expressed in thousandths of the programmed dimensions.
Entry of the scaling factor and display on screen.
