5 - 36 en-938821/2
Selection of a block, insertion of a string at the end of a block and insertion of a new block
System in edit mode and programme to be modified not displayed.
Original blocks Modified blocks
N20 T01 D01 M06 N20 T01 D01 M06 (CUTTER DIA=10)
N30 S700 M03 N30 S700 M03
N40 G00 Z-3
Enter "N20". ☞
Selection of block N20.
Enter "#;; (CUTTER DIA=10)". ☞
Addition of comment "(CUTTER DIA=10)" at the end of block N20.
Select the next block (N30). ☞
➞
Enter "+N40 G00 Z-3". ☞
Addition of block "N40 G00 Z-3" after block N30.
Modification of a block after transfer to dialogue line
System in edit mode, block to be modified (old block N40) selected and indicator
OVER
(overtype mode) displayed in
the status window.
Original block Modified block
N40 G00 G41 X8 Y-10 N50 G41 X18 Y-10
Enter "#". ☞
Transfer of old block N40 to the dialogue line.
Move the cursor 2 characters to the right. ☞
➞
➞
Overtype the "4" with a "5". ☞
%
5
Move the cursor 3 characters to the right (press 3 times). ☞
➞
Delete string "G00 " (press 4 times). ☞
line
DEL
char
Move the cursor 5 characters to the right (press 5 times). ☞
➞
Select the text insertion mode. ☞
INS/
OVER
Display of the
INS
indicator (text insertion) in the status window.
Insert a "1". ☞
!
1
Confirm the block. ☞
Replacement of the old block N40 by "N50 G41 X18 Y-10".
