C - 16 en-938821/2
C.1.2.8 Remote RS 422 Line Cable on Machine Panel or Compact Panel
Remote RS 422 Line Cable on Machine Panel
12 43
24 VDC
1
13
14
25
Solder side
Solder side
8
1
9
15
15
contacts
6
9
5
1
9
contacts
1 - 9- or 15-contact male Sub.D connector on NUM side
2 - Shielded cable with 2 twisted pairs and 1 isolated conductor (0.14 mm
2
minimum cross sectional area)
3 - 2-wire cable (optional, used for supply of the NUM drive)
4 - Remote 25-contact female Sub.D connector on the machine panel
T(A) +
R(A) +
R(B) -
0 V
24 VDC
PROTECTIVE
EARTH
T(B) -
CONNECTOR
BODY
9
6
1
5
7
4
24 VDC
CONNECTOR
BODY
T(B) -
R(A) +
R(B) -
PROTECTIVE
EARTH
2
9
4
11
T(A) +
0 V
7
9
4
6
1
5
SUB.D
9 cont. 15 cont.
REMARK When contact 24 of the remote line is connected to a power supply, the drive must
not be supplied by the jack connector.
