C - 22 en-938821/2
C.2.1.2 Setting up the Link
Connect the microcomputer serial port to a serial line of the CNC.
Set the serial line parameters (See table below).
Start bits Data bits Stop bits Parity
CNC side (See 8.3) 1 8 1 none
PC side 1 7 1 even
Start transferring files on the microcomputer
(The procedure varies with the software used).
Use of APA 10
Procedure described in the manual "APA 10 - PLC PROGRAMMING AID SOFTWARE FOR IBM PC/PS AND
COMPATIBLE".
Use of NUM TRAINING PACKAGE
Procedure described in the manual "NUM TRAINING PACKAGE - OPERATOR MANUAL".
Use of communication software
This procedure is described in the documentation for the software used.
For the NUM PLCTool software, See PLCTool Ladder Language Programming Tool manual.
C.2.2 Tape Reader/Punch
Use a serial link connecting cable in accordance with the instructions of Sections C.1.3 and C.1.4, and with the
peripheral device documentation.
C.2.2.1 Numerical Control / Peripheral Device Connection
Tape Readers
Type of reader Recommended data rate
GNT 27 9600 bauds
GNT 28
ZIP 30 TERMINAL 300 bauds
Tape Punches
Type of puncher Recommended data rate
GNT 3601 600 bauds
FACIT 600 bauds
