Operator Panel Description
en-938821/2 3 - 19
3
3.3.2.4 JOG Softkey Functions
Selection of jog type:
HANDW
Axis jog using handwheel.
.001
.01
.1
1
10
100
1000
10000
Jog in increments of 0.001 to 10,000 µm.
FREE
Continuous axis jog using push-buttons.
3.3.2.5 Tool Softkey Functions
Modification of tool dimensions and wear offsets:
TLCOMP
Input of tool dimensions via the keyboard (See 5.2.2.2).
WEAR +
Input of tool wear offsets (See 5.2.2.4).
L or X
Wear offset on length L (milling) or on the dimension along the X axis (turning).
R or Z
Wear offset on radius R (milling) or on the dimension along the Z axis (turning).
WEAR 0
Wear offset cancel (See 5.2.2.4).
Special Case of the Compact Panel: Functions of the Tool Softkeys
The Tool softkeys contain the symbols L, R and @ for entry of tool offsets.
