Numark MIXDECK EXPRESS BLACK User Manual

PW43200SAA01 AC Power Supply Cord Long 2.0m SAA (04)
PW43200AR01 AC Power Supply Cord Long 2.0m AR (05)
PW33200KS01 AC Power Supply Cord Long 2.0m KS (06)
PW22200JIS02 AC Power Supply Cord Long 2.0m JIS (07)
PW43200SAA01 AC Power Supply Cord Long 2.0m SAA(08)
0.1 RU0704441 Heat Conductive Rubber 2 48
0.1 RU0730605 RUBBER FOOT 4 52
0.1 RU1104413 RUBBER 2 46
0.1 SC0305FIBI Screw φ3X5MM 4 26
0.1 SC0306RINI SCREW M3X6 PPN 8
0.1 SC0308BIBI Screw ST BID30*08STL BZN 2 64
0.1 SC0308PBBI Screw M3X8 PBB Tapping 6 50
0.1 SC0308PBNI Screw 66 19
0.1 SC0310RBBI Screw M3X10 PPB Tapping 9 58
0.1 SC0314PBNI Screw M3X14 PPN Tapping 2 70
0.1 SC0314PMJI Screw M3X14 PPN 1 61
0.1 SC0316PBBI SCREW M3X16 PPB TAPPING 5 51
0.1 SC2606RINI SCREW M2.6X6 PPN 8
0.1 SPSSNPY041 SWITCHING POWER(INTERNAL) 5V/3 1 43
0.1 TWPT11106441 Knob Assembly 14 21
..2 PT11106441 Knob 14
..2 PT11106449 Decorative 14
0.1 WR0920002001 Isolation Cable 9 pin Single R 1 72
0.1 WRUSB05200030W1 Isolation Cable USB 2.0 5Pin S 2
0.1 WS073307IC Washer Flat 3 62
0.1 WS1306505 Washer FLAT 13*6.5*0.5MM 2 6
0.1 WS663309IC Spring Washer 3# 1 68
0.1 TWBACDM-M105C03 Slot-in Loader Assembly(RoHM) 2 24
..2 BACDM-M105C Slot-in Loader CDM-M105C-200 2
..2 LA67YH47 WARNING LABEL 2
..2 SC0204BIPI Screw M2X4 PBN 8
..2 WS663309IC Spring Washer 3# 8
..2 TWPC15C00801 SERVO PCB Assembly 1
...3 CS102K5003X7R CCAP SMD 1nF/50V 10% 0603 X7R 3 C106,CC1,4
...3 CS103K5003X7R CCAP SMD 0.01uF/50V 10% 0603 X7R 3 C110,CC5,8
...3 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 24
C102,104,107,113~115,117,121,123,125,127,
129,130,132,134~136,140~142,144~147
...3 CS182K5003X7R CCAP SMD 1.8nF/50V 10% 0603 X7R 1 C105
...3 CS300J5003NPO CCAP SMD 30pF/50V 5% 0603 NPO 2 C118,119
...3 CS471J5003NPO CCAP SMD 470pF/50V 5% 0603 NPO 1 C137
...3 CS681J5003NPO CCAP SMD 680pF/50V 5% 0603 NPO 1 C126
...3 DIPHIR928-6C-F Infrared radiate diode 2 LED100,101
...3 ECS10616B Capacitor Electrolytic 10uF/16V 1 C122
...3 ECS10716D Capacitor Electrolytic 100uF/16V 10 C101,103,108,109,116,120,128,131,133,143
...3 ECS22450B ECAP 0.22uF/50V 4*5.4mm SMD 1 C112
...3 ECS33550B Capacitor Electrolytic SMD 3.3uF/50V 1 C111
...3 FCN1T1003001 FCN Down Touch ZIF SMD Pitch=1.0mm 1 FCN102
...3 FCN2T1001701 FCN Dual Touch SMD Pitch=1.0mm 1 FCN101
...3 ICBA033FP IC BA033FP 1 IC103
...3 ICBA5968FP IC BA5968FP 1 IC102
...3 ICBU9543KV IC BU9543KV 1 IC101
...3 PC15C008 ROHM Servo PCB 1 -
...3 RS000010J03 RESISTOR 0Ω 5% SMD 0603 2 R121,131
...3 RS001410F03 RESISTOR 14Ω 1% SMD 0603 1 R154
...3 RS001K10F03 RESISTOR 1K 1% SMD 0603 2 R107,115
...3 RS001M10F03 RESISTOR 1M 1% SMD 0603 1 R119
...3 RS002010F03 RESISTOR 20Ω 1% SMD 0603 2 R132,155
...3 RS002210F03 RESISTOR 22Ω 1% SMD 0603 1 R120
...3 RS010010F03 RESISTOR 100Ω 1% SMD 0603 6 R112~114,116~118
...3 RS010K10F03 RESISTOR 10K 1% SMD 0603 6 R122,127,129,142,143,150
...3 RS012K10F03 RESISTOR 12K 1% SMD 0603 1 R130
...3 RS015K10F03 RESISTOR 15K 1% SMD 0603 2 R105,106
