Numark MIXDECK EXPRESS BLACK User Manual

..2 ICAIC1117-18PY IC REG IC AIC1117-18PY 1 IC100
..2 ICAIC809N46PU IC AIC809N46PU 1 IC302
..2 ICAK4346 IC AK4346 24Bit 6channel DAC V 1 IC3
..2 ICAP1501K5L IC AP1501K5L 1 U420
..2 ICAP7165SPG IC AP7165-SPG-13 1 IC205
..2 ICBA033FP IC BA033FP 2 IC30,204
..2 ICBA05FP IC BA05FP 1 U421
..2 ICBA4558F IC BA4558F 6 IC501~506
..2 ICDA1191F IC DA1191F 2 IC401A,401B
..2 ICDRV602 IC DRV602 2 IC402A,402B
..2 ICDSPB56724AG IC DSPB56724AG 1 IC201
..2 ICK4S281632I IC K4S281632I 1 IC206
..2 ICSN74LV373APWR IC SN74LV373APWR 2 IC202,203
..2 ICSN74LVC3G14 IC SN74LVC3G14 5 IC5,303~306
..2 ICXCBDSP56367 IC XCBDSP56367 1 IC101
..2 ICYH2K09C01M
IC YH2K09C01M (MASK ET5126-YA+PROGRAM LQFP)
1 U100
..2 ICYH2K271 IC YH2K271 (TMP86FS49BFG+Program) 1 IC301
...3 ICMP86FS49BFG-1 IC TMP86FS49BFG Blank 1 -
..2 ICYHFRC269 IC YHFRC269 (MCF51JU32VFM QFN32+Program) 1 IC4
...3 ICMCF51JU32VFM IC MCF51JU32VFM QFN32 1 -
..2 ICYHFRC294 IC YHFRC294 (MX25L8006EM2I-12G+Program) 1 IC200
...3 ICMX25L8006EM2I IC MX25L8006EM2I-12G 1 -
..2 JK6L0670CBKA6A 6.4φ Phone JACK 7PIN 90° Fem 1 MIC501
..2 JK7TU-301-AP AC JACK 3P 90° PIN 1 JK1
..2 JKLX-1601HR-3 XLR JACK 3PIN 90° MALE 2 J502,504
..2 LP1020010 PIN JACK 1 JK501
..2 PC14C023 Main PCB 1 -
..2 RJ1019-09 4PIN RCA JACK 1 J501
..2 RS000010J03 RESISTOR 0Ω 5% SMD 0603 18
R34,35,134,218,219,230,249,332,502,510,515
,522,531,544,569,576,581,587
..2 RS001K10F03 RESISTOR 1K 1% SMD 0603 10 R252,501,512,519,530,543,555,564,572,584
..2 RS001M10F03 RESISTOR 1M 1% SMD 0603 5 R37,117,248,320,590
..2 RS002710F03 RESISTOR 27Ω 1% SMD 0603 6 R41,42,119,120,123,124
..2 RS002K10F03 RESISTOR 2K 1% SMD 0603 1 R253
..2 RS003310F03 RESISTOR 33Ω 1% SMD 0603 6 R14,15,133,200,220,225
..2 RS004710F03 RESISTOR 47Ω 1% SMD 0603 3 R254,321,322
..2 RS010010F03 RESISTOR 100Ω 1% SMD 0603 68
R11A,11B,12A,12B,13,25,26,28~33,36,44,125
,127,132,135~148,151~154,213,216,217,221~
223,236~238,246,402A,402B,412A,412B,413
A,413B,529,539~542,550,560,562,593,594~6
00
..2 RS010K10F03 RESISTOR 10K 1% SMD 0603 114
R7A,7B,8A,8B,16~24,27,38,39,100~115,126,1
28~131,150,155,156,201~212,224,226,233,24
3~245,247,250,301~319,323,325~331,333,33
4~343,345~347,425,508,518,526,532,535,552
,556,559,567,578,589,591
..2 RS015010F03 RESISTOR 150Ω 1% SMD 0603 16
R227~229,231,239~242,401A,401B,403A,403
B,404A,404B,405A,405B
..2 RS015K10F03 RESISTOR 15K 1% SMD 0603 9 R4A,4B,6A,6B,43,116,118,121,122
..2 RS01K310F03 RESISTOR 1.3K 1% SMD 0603 1 R426
..2 RS01K510F03 RESISTOR 1.5K 1% SMD 0603 1 R40
..2 RS022010F03 RESISTOR 220Ω 1% SMD 0603 8 R214,215,234,235,420~423
..2 RS027010F03 RESISTOR 270Ω 1% SMD 0603 1 R324
..2 RS036K10F03 RESISTOR 36K 1% SMD 0603 4 R407A,407B,410A,410B
..2 RS047K10F03 RESISTOR 47K 1% SMD 0603 14
R504,511,517,525,534,536,545,551,561,571,5
77,580,583,588
..2 RS04K710F03 RESISTOR 4.7K 1% SMD 0603 1 R344
..2 RS056010F03 RESISTOR 560Ω 1% SMD 0603 1 R149
..2 RS05K110F03 RESISTOR 5.1K 1% SMD 0603 4 R507,521,568,579
..2 RS05K610F03 RESISTOR 5.6K 1% SMD 0603 8 R505,513,523,528,548,554,565,574
..2 RS062K10F03 RESISTOR 62K 1% SMD 0603 4 R406A,406B,411A,411B
..2 RS068K10F03 RESISTOR 68K 1% SMD 0603 4 R408A,408B,409A,409B
..2 RS08K210F03 RESISTOR 8.2K 1% SMD0603 4 R9A,9B,10A,10B
..2 RS09K110F03 RESISTOR 9.1K 1% SMD 0603 2 R557,563
..2 RS100K10F03 RESISTOR 100K 1% SMD 0603 3 R251,538,547

Numark MIXDECK EXPRESS BLACK Specifications

General

Brand	Numark
Model	MIXDECK EXPRESS BLACK
Category	DJ Equipment
Language	English
