Numark MIXDECK EXPRESS BLACK User Manual

...3 FCN1T1003001 FCN Down Touch ZIF SMD Pitch=1.0mm 2 FCN105,303
...3 IC2-77-0103 Touch IC (2-77-0103) 1 IC204
...3 IC74HC595 IC 74HC595 2 IC201,202
...3 ICAIC809N46PU IC AIC809N46PU 1 IC301
...3 ICSN74LVC3G14 IC SN74LVC3G14 1 IC203
...3 ICYH2K261 IC YH2K261 (TMP86FS49BFG+PROGRAM) 1 IC302
....4 ICTMP86FS49BFG IC TMP86FS49BFG Blank 1 -
...3 JK0SCU101SFN0W A-TYPE USB WHITE(USB1.1) 1 USB201
...3 JW5206T Jumping Wire 127 J1~55,57~126,128,129
...3 LD-005K6CS LED Blue 1 LED214
...3 LD-005YLN15S LIQUID-EMITTING DIODE AMBER AS 16 LED118,201~213,215,216
...3 MT0701840 EARTHER METAL 1 (MT1)
...3 RS000004J06 RESISTOR 0Ω 5% SMD 1206 2 RS2,3
...3 RS000008J05 RESISTOR 0Ω 5% SMD 0805 10 RS1,4~9,11~13
...3 RS001M10F03 RESISTOR 1M 1% SMD 0603 1 R305
...3 RS002210F03 RESISTOR 22Ω 1% SMD 0603 30 R322,326~335,339~357
...3 RS010010F03 RESISTOR 100Ω 1% SMD 0603 3 R249,250,310
...3 RS010K08F05 RESISTOR 10K 1% SMD 0805 4 R302,307,309,337
...3 RS010K10F03 RESISTOR 10K 1% SMD 0603 21
R243,244,247,303,304,308,311~321,323,324,
325,338
...3 RS012K10F03 RESISTOR 12K 1% SMD 0603 2 R240,242
...3 RS015K10F03 RESISTOR 15K 1% SMD 0603 1 R237
...3 RS018010F03 RESISTOR 180Ω 1% SMD 0603 9 R201,202,208~211,214~216
...3 RS01K510F03 RESISTOR 1.5K 1% SMD 0603 2 R223,224
...3 RS020K10F03 RESISTOR 20K 1% SMD 0603 1 R234
...3 RS022K10F03 RESISTOR 22K 1% SMD 0603 2 R217,218
...3 RS027010F03 RESISTOR 270Ω 1% SMD 0603 2 R301,306
...3 RS033010F03 RESISTOR 330Ω 1% SMD 0603 2 R219,220
...3 RS036010F03 RESISTOR 360Ω 1% SMD 0603 8 R203~207,212,213,251
...3 RS03K310F03 RESISTOR 3.3K 1% SMD 0603 2 R225,226
...3 RS03K910F03 RESISTOR 3.9K 1% SMD 0603 4 R227~230
...3 RS047K10F03 RESISTOR 47K 1% SMD 0603 2 R221,222
...3 RS05K610F03 RESISTOR 5.6K 1% SMD 0603 2 R231,232
...3 RS068K10F03 RESISTOR 68K 1% SMD 0603 1 R246
...3 RS06K810F03 RESISTOR 6.8K 1% SMD 0603 2 R233,235
...3 RS07K510F03 RESISTOR 7.5K 1% SMD 0603 2 R236,238
...3 RS08K210F03 RESISTOR 8.2K 1% SMD0603 2 R239,241
...3 RS100K10F03 RESISTOR 100K 1% SMD 0603 1 R248
...3 SWDC11B2021431 Switch Rotational Encode 20Pul 1 ENC201
...3 SWEVQ11L05R Switch Tact 5mm 160g Horizonta 19 SW201~219
...3 TE622000501 5P CONNECTOR 1 (TE201)
...3 TR2SK1828 Mosfet N-CH 20V MAIN 2-Pin 2 Q202,204
...3 VRS10310016 Potentiometer Slide 10K 2BM 10 1 VR201
...3 XTM16000X6 Crystal 16MHZ 49US SMD Fundame 1 X301
..2 TWPC14C025B01 CROSS FADER PCB Assembly 1 77
...3 JW5206T Jumping Wire 1 J127
...3 TE622000701 7P CONNECTOR 1 (TE502)
...3 VRS50304528 Potentiomeper Slide 50K3BX4 45 1 VR506
..2 TWPC14C025C01 Spare PCB Assembly 1 66
0.1 TWPC14C02601 Mixer PCB Assembly 1 4
..2 AL2-71-0074 IC TL074 QUAD OPAMP 6 IC402,403,502,503,602,603
..2 AL2-72-0339 IC LM339 ANALOG COMP 4 IC802,803,805,806
..2 CN0720001004 Flat Cable 12Pin Pitch 2.0mm S 1 TE501
..2 CS100J5003NPO CCAP SMD 10pF/50V 5% 0603 NPO 8 C401,402,501,502,601,602,701,702
..2 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 10 C419,420,519,520,619,620,901,902,907,908
..2 CS102K5003X7R CCAP SMD 1nF/50V 10% 0603 X7R 6 C414,416,514,516,614,616
..2 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 41
C403,404,413,415,421~424,503,504,513,515,
521~524,603,604,613,615,621~624,703,704,8
01,802,805~810,903,904,909,910,CC24~26
..2 CS123K5003X7R CCAP SMD 0.012UF/50V 10% 0603 X7R 6 C417,418,517,518,617,618
..2 CS183K5003X7R CCAP SMD 0.018UF/50V 10% 0603 X7R 6 C408,410,508,510,608,610
