...3 RS018K10F03 RESISTOR 18K 1% SMD 0603 4 R101~104
...3 RS020K10F03 RESISTOR 20K 1% SMD 0603 2 R148,149
...3 RS022K10F03 RESISTOR 22K 1% SMD 0603 4 R138,139,146,147
...3 RS02K710F03 RESISTOR 2.7K 1% SMD 0603 1 R123
...3 RS033010F03 RESISTOR 330Ω 1% SMD 0603 4 R140,141,144,145
...3 RS03K310F03 RESISTOR 3.3K 1% SMD 0603 1 R151
...3 RS043K10F03 RESISTOR 43K 1% SMD 0603 1 R128
...3 RS047010F03 RESISTOR 470Ω 1% SMD 0603 2 R111,156
...3 RS04R710F03 RESISTOR 4.7Ω 1% SMD 0603 2 R109,110
...3 RS068K10F03 RESISTOR 68K 1% SMD 0603 1 R137
...3 RS06K810F03 RESISTOR 6.8K 1% SMD 0603 1 R124
...3 RS07K510F03 RESISTOR 7.5K 1% SMD 0603 1 R125
...3 RS08K210F03 RESISTOR 8.2K 1% SMD0603 1 R126
...3 RS100K10F03 RESISTOR 100K 1% SMD 0603 1 R108
...3 SW1AB491-310T40 Switch push Single Row SMD 1 SW100
...3 TR2SA1037ASM TRANSISTOR 2SA1037AKR PNP 1 Q101
...3 TR2SC2412KSM TRANSISTOR 2SC2412K NPN 2 Q102,103
...3 XTM16934X6 Crystal 16.9344MHz 49US SMD 1 X101
0.1 TWPC14C02302 Main PCB Assembly 1 59
..2 AL2-71-0074 IC TL074 QUAD OPAMP 2 IC1,2
..2 AL4-08-0402 Con USB 4-Pin Female PC-MNT Ho 1 J1
..2 CN0100000601 Flat Cable GND Wire Y/G Lengt 1 CN1
..2 CS100J5003NPO CCAP SMD 10pF/50V 5% 0603 NPO 4 C506,514,554,563
..2 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 14
C10A,10B,11A,11B,12A,12B,13A,13B,526,53
0,541,550~552
..2 CS102K5003X7R CCAP SMD 1nF/50V 10% 0603 X7R 16
C8A,8B,9A,9B,414A,414B,415A,415B,505,51
0,519,524,536,543,555,561
..2 CS103K5003X7R CCAP SMD 0.01uF/50V 10% 0603 X7R 15 C226,228,237~242,244,306~311
..2 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 102
C1,3,5,14A,14B,16,18,30~32,101,103~111,11
3~129,200~214,217~225,227,229~236,243,24
5,303~305,401A,401B,402A,402B,420,429,43
0,432,433,501,509,515,521,529,531,532,537,
545,547,553,557,CC102~107
..2 CS105K1603X7R CCAP SMD 1uF/16V 10% 0603 X7R 10
C403A,403B,407A,407B,408A,408B,409A,409
B,413A,413B
..2 CS106K1606X7R CCAP SMD 10uF/16V 10% 1206 X7R 2 C17,21
..2 CS150J5003NPO CCAP SMD 15pF/50V 5% 0603 NPO 8
C405A,405B,406A,406B,410A,410B,411A,411
B
..2 CS180J5003NPO CCAP SMD 18pF/50V 5% 0603 NPO 2 C19,20
..2 CS220J5003NPO CCAP SMD 22pF/50V 5% 0603 NPO 2 C215,216
..2 CS221J5003NPO CCAP SMD 220pF/50V 5% 0603 NPO 1 C112
..2 CS273K5003X7R CCAP SMD 0.027uf/50V 10% 0603 X7R 2 C528,539
..2 CS300J5003NPO CCAP SMD 30pF/50V 5% 0603 NPO 12 C100,102,301,302,421~428
..2 CS330J5003NPO CCAP SMD 33pF/50V 5% 0603 NPO 2 C22,23
..2 CS471J5003NPO CCAP SMD 470pF/50V 5% 0603 NPO 4 C404A,404B,412A,412B
..2 CS475K1605X5R CCAP SMD 4.7uF/16V 10% 0805 X5R 3 C2,4,15
..2 CS822K5003X7R CCAP SMD 8.2nF/50V 10% 0603 X7R 2 C527,538
..2 DIEN1N4148WSM Diode SMD 6 D404,405,501~504
..2 DISDMBRD835LT4G Diode 1 D420
..2 EC10616TS Capacitor Electrolytic 10uF/16V 14
C6A,6B,7A,7B,503,511,549,560,EC103,200,2
01,205,403A,403B
..2 EC10625TL Capacitor Electrolytic low-lea 10uF/25V 1 C568
..2 EC10625TS Capacitor Electrolytic 10uF/25V 2 C516,534
..2 EC10716T Capacitor Electrolytic 100uF/16V 7 EC30,31,202~204,420,429
..2 EC10825 Capacitor Electrolytic 1000uF/25V 3 C431,434,435
..2 EC22616T Capacitor Electrolytic 22uF/16V 4 EC401A,401B,402A,402B
..2 EC22725T Capacitor Electrolytic 220uF/25V 1 C569
..2 EC33725TLE Capacitor Electrolytic low ESR 330uF/25V 6 EC422~427
..2 EC47550TS Capacitor Electrolytic 4.7uF/50V 1 EC301
..2 EC47616T Capacitor Electrolytic 47uF/16V 20
C502,508,512,518,522,523,525,533,535,542,5
44,546,548,556,562,564,567,EC101,102,206
..2 EC47716T Capacitor Electrolytic 470uF/16V 1 EC100
..2 FCN2S1003001 FCN Dual Touch 180° Pitch=1.0mm 4 FCN301,302,TE401,501
..2 FSMSMD200 Fuse PTC MSMD200 8V/2A SMD 1 FS100
