Numark MIXDECK EXPRESS BLACK User Manual

..2 RS4K4210F03 RESISTOR 4.42K 1% SMD 0603 4 R1A,1B,2A,2B
..2 RS560K10F03 RESISTOR 560K 1% SMD 0603 1 R585
..2 RS7K1510F03 RESISTOR 7.15K 1% SMD 0603 1 R424
..2 RS7K3210F03 RESISTOR 7K32±1% SMD 0603 4 R3A,3B,5A,5B
..2 RS8K2510F03 RESISTOR 8.25K 1% SMD 0603 2 R537,546
..2 SW8216-B2C01 Switch Power Push Single Row 1 SW1
..2 SWDS-11L-C2 Switch Slide 2P2T 2 SW501,502
..2 TE10200502 5P CONNECTOR 2 (TE100,101)
..2 TE10200601 6P CONNECTOR 2 (TE102,201)
..2 TE611500101 Connector 1 (G1)
..2 TE612000402 4P CONNECTOR 1 (TE2)
..2 TE612000901 9P CONNECTOR 1 (TE503)
..2 TE613960601 6P CONNECTOR 1 (TE402)
..2 TE617920201 Terminal(2P 3UCDJ) 1 (TE1)
..2 TR2SA1037ASM TRANSISTOR 2SA1037AKR PNP 1 Q509
..2 TR2SD2114KSM TRANSISTOR 2SD2114K NPN 10 Q501~508,510,511
..2 TRMMBT3904LT1 TRANSISTOR MMBT3904LT1 NPN 2 Q1,2
..2 UHDRRI125-101M Inductor, 100UH±20% 1.3A SMD 1 L420
..2 XTM06000X6 Crystal 6MHZ 49US SMD Fundamen 1 X100
..2 XTM08000XA1 Crystal Oscillator 8MHZ 5*3.2m 1 X2
..2 XTM11289X6 Crystal 11.2896MHz 49US SMD Fu 1 X200
..2 XTM16000X6 Crystal 16MHZ 49US SMD Fundame 1 X301
0.1 TWPC14C02401 LEFT CTRL PCB Assembly 1
..2 PC14C024 LEFT CTRL PCB 1
..2 TWPC14C024A01 LEFT CTRL PCB Assembly 1 18
...3 AL2-50-4149 Diode Single 1N4148 100V 200mA 2 D101,102
...3 AL2-51-4403 TRANSISTOR 2N4403 PNP 2 Q102,103
...3 AL2-65-0114 IC 74AHC1G14 1 IC105
...3 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 5 C101,104,108~110
...3 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 19
C102,103,105~107,111,112,309,CC05~07,09,
11,12,18,19,21,22,28
...3 CS180J5003NPO CCAP SMD 18pF/50V 5% 0603 NPO 1 R145
...3 DIPH574 Photo Sensor 2 SEN101,102
...3 EC10716TS Capacitor Electrolytic 100uF/16V 1 EC101
...3 FCN1T1001602 FCN Down Touch ZIF SMD Pitch=1.0mm 2 FCN104,301
...3 FCN1T1003001 FCN Down Touch ZIF SMD Pitch=1.0mm 1 FCN106
...3 IC74HC595 Integrated Circuit 3 IC101,102,104
...3 ICSN74LVC3G14 IC SN74LVC3G14 SSOP8 1 IC103
...3 JK0SCU101SFN0W A-TYPE USB WHITE(USB1.1) 1 USB101
...3 JW5206T Jumping Wire 110 J1~7,9~82,84~103,105~113
...3 LD-005K6CS LED Blue 1 LED114
...3 LD-005YLN15S LIQUID-EMITTING DIODE AMBER AS 16 LED101~113,115~117
...3 MT0701840 EARTHER METAL 1 (MT1)
...3 RS000004J06 RESISTOR 0Ω 5% SMD 1206 7 RS1,3,10,11,15~17
...3 RS000008J05 RESISTOR 0Ω 5% SMD 0805 9 RS2,4~9,12,13
...3 RS010010F03 RESISTOR 100Ω 1% SMD 0603 2 R149,150
...3 RS010K10F03 RESISTOR 10K 1% SMD 0603 1 R147
...3 RS012K10F03 RESISTOR 12K 1% SMD 0603 2 R140,142
...3 RS015K10F03 RESISTOR 15K 1% SMD 0603 1 R137
...3 RS018010F03 RESISTOR 180Ω 1% SMD 0603 9 R101,102,108~111,114~116
...3 RS01K510F03 RESISTOR 1.5K 1% SMD 0603 2 R123,124
...3 RS020K10F03 RESISTOR 20K 1% SMD 0603 1 R134
...3 RS022K10F03 RESISTOR 22K 1% SMD 0603 2 R117,118
...3 RS033010F03 RESISTOR 330Ω 1% SMD 0603 2 R119,120
...3 RS036010F03 RESISTOR 360Ω 1% SMD 0603 8 R103~107,112,113,143
...3 RS03K310F03 RESISTOR 3.3K 1% SMD 0603 2 R125,126
...3 RS03K910F03 RESISTOR 3.9K 1% SMD 0603 4 R127~130
...3 RS047K10F03 RESISTOR 47K 1% SMD 0603 2 R121,122
...3 RS05K610F03 RESISTOR 5.6K 1% SMD 0603 2 R131,132
...3 RS068K10F03 RESISTOR 68K 1% SMD 0603 1 R146
...3 RS06K810F03 RESISTOR 6.8K 1% SMD 0603 2 R133,135
...3 RS07K510F03 RESISTOR 7.5K 1% SMD 0603 2 R136,138
...3 RS08K210F03 RESISTOR 8.2K 1% SMD0603 2 R139,141
