Numark MIXDECK EXPRESS BLACK User Manual

..2 CS184K1603X7R CCAP SMD 0.18UF/16V 10% 0603 X7R 6 C407,409,507,509,607,609
..2 DIEN1N4148WSM Diode SMD 4 D801~804
..2 EC10550TS Capacitor Electrolytic 1uF/50V 4 C803,804,811,812
..2 EC10616TS Capacitor Electrolytic 10uF/16V 8 C405,406,505,506,605,606,705,706
..2 EC22616TS Capacitor Electrolytic 22uF/16V 12 C425,426,525,526,625,626,905,906,911~914
..2 EC33550TS Capacitor Electrolytic 3.3uF/50V 6 C411,412,511,512,611,612
..2 FCN1T1001001 FCN Down Touch Pitch 1.0mm 90 1 FCN102
..2 FCN1T1003001 FCN Down Touch ZIF SMD Pitch=1.0mm 1 FCN401
..2 ICBA4558F IC BA4558F 7 IC401,501,601,701,801,901,902
..2 LD-005YLN15S LIQUID-EMITTING DIODE AMBER AS 6 LED901~906
..2 LDKPT-1608SECK Liquid-emitting Diode amber SMD 4 LD803,810,LED802,809
..2 LDKPT-1608SURCK Liquid-emitting Diode Red SMD 2 LED801,808
..2 LDLTST-C190KSKT Liquid-emitting Diode Amber SMD 8 LD804~807,811~814
..2 NM1106125 Velvet Carpet 3 (VR405,505,605)
..2 NM1106129 Velvet Carpet 1 (VR901)
..2 PC14C026 Main PCB 1 -
..2 PT111048005 Fixed Base,LED 6 (LED901~906)
..2 RS001K10F03 RESISTOR 1K 1% SMD 0603 10 R805,806,813,821,901~903,924~926
..2 RS001M10F03 RESISTOR 1M 1% SMD 0603 6 R403,404,503,504,603,604
..2 RS010010F03 RESISTOR 100Ω 1% SMD 0603 10 R437~442,703,704,810,811
..2 RS010K10F03 RESISTOR 10K 1% SMD 0603 26
R405,406,431,432,435,436,505,506,531,532,5
35,536,605,606,631,632,635,636,910~91,916
..2 RS015K10F03 RESISTOR 15K 1% SMD 0603 6 R401,402,501,502,601,602
..2 RS016K10F03 RESISTOR 16K 1% SMD 0603 2 R537,538
..2 RS01K810F03 RESISTOR 1.8K 1% SMD 0603 2 R812,820
..2 RS020K10F03 RESISTOR 20K 1% SMD 0603 10 R701,702,904~909,920,921
..2 RS024010F03 RESISTOR 240Ω 1% SMD 0603 18
R414,417,420,423,426,429,514,517,520,523,5
26,529,614,617,620,623,626,629
..2 RS024K10F03 RESISTOR 24K 1% SMD 0603 2 R801,802
..2 RS02K710F03 RESISTOR 2.7K 1% SMD 0603 18
R413,416,419,422,425,428,513,516,519,522,5
25,528,613,616,619,622,625,628
..2 RS033K10F03 RESISTOR 33K 1% SMD 0603 2 R742,743
..2 RS039010F03 RESISTOR 390Ω 1% SMD 0603 2 R818,826
..2 RS047K10F03 RESISTOR 47K 1% SMD 0603 2 R922,923
..2 RS04K710F03 RESISTOR 4.7K 1% SMD 0603 6 R433,434,533,534,633,634
..2 RS051010F03 RESISTOR 510Ω 1% SMD 0603 2 R816,824
..2 RS056010F03 RESISTOR 560Ω 1% SMD 0603 2 R817,825
..2 RS056K10F03 RESISTOR 56K 1% SMD 0603 12
R415,418,424,427,515,518,524,527,615,618,6
24,627
..2 RS062010F03 RESISTOR 620Ω 1% SMD 0603 2 R815,823
..2 RS062K10F03 RESISTOR 62K 1% SMD 0603 6 R421,430,521,530,621,630
..2 RS068010F03 RESISTOR 680Ω 1% SMD 0603 4 R807,809,819,827
..2 RS06K810F03 RESISTOR 6.8K 1% SMD 0603 2 R914,915
..2 RS082010F03 RESISTOR 820Ω 1% SMD 0603 2 R814,822
..2 RS100K10F03 RESISTOR 100K 1% SMD 0603 2 R803,804
..2 RS200K10F03 RESISTOR 200K 1% SMD 0603 12
R408,409,411,412,508,509,511,512,608,609,6
11,612
..2 RS270K10F03 RESISTOR 270K 1% SMD 0603 6 R407,410,507,510,607,610
..2 RS330K10F03 RESISTOR 330K 1% SMD 0603 1 R808
..2 SWLBC22M-15K Switch Toggle Dual Row 3 SW401,501,601
..2 SWSFPC14MA01 Switch Push 2P2T Dual Row Lock 3 SW901~903
..2 TRBC857B TRANSISTOR BC857B PNP 3 Q801~803
..2 VRR50301704 Potentiometer Rotary Volume Sh 9 VR402~404,502~504,602~604
..2 VRR50301705 Potentiometer Rotary Volume Sh 2 VR701,902
..2 VRR50301706 Potentiometer Rotary Volume Sh 3 VR401,501,601
..2 VRS50302005 Potentiometer Slide 50KB Trave 1 VR901
..2 VRS50304527 Potentiometer Slide 50KA Trave 3 VR405,505,605
