...3 RS100K10F03 RESISTOR 100K 1% SMD 0603 1 R148
...3 SWDC11B2021431 Switch Rotational Encode 20Pul 1 ENC101
...3 SWEVQ11L05R Switch Tact 5mm 160g Horizonta 19 SW101~119
...3 TE622000501 5P CONNECTOR 1 (TE101)
...3 TR2SK1828 Mosfet N-CH 20V MAIN 2-Pin 2 Q101,104
...3 VRS10310016 Potentiometer Slide 10K 2BM 10 1 VR101
..2 TWPC14C024B01 FRONT PCB Assembly 1 55
...3 AL2-71-0074 IC TL074 QUAD OPAMP 1 IC710
...3 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 6 C714,715,719~722
...3 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 8 C718,723~727,732,733
...3 CS272K5003X7R CCAP SMD 2.7nF/50V 10% 0603 X7R 1 C717
...3 CS331J5003NPO CCAP SMD 330pF/50V 5% 0603 NPO 2 C710,711
...3 DIEN1N4148WSM Diode SMD 4 D710~713
...3 EC10625TL Capacitor Electrolytic low-lea 10uF/25V 1 C740
...3 EC10716T Capacitor Electrolytic 100uF/16V 4 C728~731
...3 EC22616T Capacitor Electrolytic 22uF/16V 2 C734,737
...3 EC22725T Capacitor Electrolytic 220uF/25V 1 C741
...3 EC47616T Capacitor Electrolytic 47uF/16V 3 C712,713,716
...3 ICNJM4556AM IC NJM4556AM 2 IC711,712
...3 JK-3537 3.5mm Phone Jack 9P 90° DIP F 1 JK710
...3 JK6L0670CBKA6A 6.4φ Phone JACK 7PIN 90° Fem 2 JK711,MIC710
...3 JW5206T Jumping Wire 8 J8,25,83,104,114~117
...3 RS000004J06 RESISTOR 0Ω 5% SMD 1206 1 RS19
...3 RS000008J05 RESISTOR 0Ω 5% SMD 0805 5 RS14,18,20,21,23
...3 RS001K10F03 RESISTOR 1K 1% SMD 0603 1 R740
...3 RS006810F03 RESISTOR 68Ω 1% SMD 0603 8 R727~734
...3 RS010010F03 RESISTOR 100Ω 1% SMD 0603 4 R710,711,742,743
...3 RS010K10F03 RESISTOR 10K 1% SMD 0603 2 R712,713
...3 RS015K10F03 RESISTOR 15K 1% SMD 0603 1 R725
...3 RS01K310F03 RESISTOR 1.3K 1% SMD 0603 4 R716~719
...3 RS02K710F03 RESISTOR 2.7K 1% SMD 0603 2 R715,726
...3 RS03K310F03 RESISTOR 3.3K 1% SMD 0603 1 R724
...3 RS047K10F03 RESISTOR 47K 1% SMD 0603 1 R739
...3 RS05K110F03 RESISTOR 5.1K 1% SMD 0603 4 R720~723
...3 RS05K610F03 RESISTOR 5.6K 1% SMD 0603 4 R735~738
...3 RS100K10F03 RESISTOR 100K 1% SMD 0603 1 R714
...3 RS560K10F03 RESISTOR 560K 1% SMD 0603 1 R741
...3 TE612000901 9P CONNECTOR 1 (TE710)
...3 TR2SA1037ASM TRANSISTOR 2SA1037AKR PNP 1 Q714
...3 TR2SD2114KSM TRANSISTOR 2SD2114K NPN 4 Q710~713
...3 VRR10403003 VR 100KB (CLICK) 2 VR710,711
...3 VRR50303007 VR 50KA 1 VR712
..2 TWPC14C024C01 Shielding PCB Assembly 1 74
0.1 TWPC14C02501 RIGHT CTRL PCB Assembly 1
..2 PC14C025 RIGHT CTRL PCB 1
..2 TWPC14C025A01 RIGHT CTRL PCB Assembly 1 5
...3 AL2-50-4149 Diode Single 1N4148 100V 200mA 2 D201,202
...3 AL2-51-4403 Transistor 2N4403 PNP SOT-23 2 Q201,203
...3 AL2-65-0114 IC 74AHC1G14 SOP-5 1 IC205
...3 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 4 C201,204,208,209
...3 CS103K5003X7R CCAP SMD 0.01uF/50V 10% 0603 X 2 C306,307
...3 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7 25
C202,203,205~207,210,212,301,302,305,310,
311,CC01,02,08,10,13~16,20,23,27,29,30
...3 CS180J5003NPO CCAP SMD 18pF/50V 5% 0603 NPO 1 R245
...3 CS220J5003NPO CCAP SMD 22pF/50V 5% 0603 NPO 1 C308
...3 CS300J5003NPO CCAP SMD 30pF/50V 5% 0603 NPO 2 C303,304
...3 DIPH574 Photo Sensor 2 SEN201,202
...3 EC10716TS Capacitor Electrolytic 100uF/16V 2 EC201,302
...3 EC47550TS Capacitor Electrolytic 4.7uF/50V 1 EC301
...3 FCN1T1001001 FCN Down Touch Pitch 1.0mm 90 1 FCN101
...3 FCN1T1001602 FCN Down Touch ZIF SMD Pitch=1.0mm 2 FCN103,302
