...3 VRS10306010
Potentiometer Slide 10KB2 20X60 Tap Single/Cetent-Lock
1 VR2
..2 TWPC10C029B01 Power LED PCB Assembly 1 29
...3 BALE48201-5A LED Fixed 1.5MM 2 (LED901,902)
...3 CN0220002001 2P Pitch 2.0mm Dual Row Length 200mm Line/ Line 1 TE902
...3 LD-005HLV RED LED 2 LED901,902
...3 RS027010F03 RESISTOR 270Ω 1% SMD 0603 2 R915,916
...3 TE812000211 2P CONNECTOR 1 (TE902)
..2 TWPC10C029C01 Power SW PCB Assembly 1 30
...3 DWLN202002 BROWN WIRE 200MM 1 CN1
...3 SW8216-B2C01 Switch Power Push Single Row 1 SW1
0.1 TWPC10C03001 MAIN PCB Assembly 1 24
..2 AL2-51-0340 DIODE POWER SCHOTTKY MBRA340T3 40V 3A 1 DZ901
..2 CS102K5003X7R CERAMIC 1nF/50V 10% 0603 X7R 6 C105,106,205,206,515,516
..2 CS103K5003X7R CERAMIC 0.01uF/50V 10% 0603 X7R 11 C35,37,47~53,303,431
..2 CS104K5003X7R CERAMIC 0.1uF/50V 10% 0603 X7R 75
C1~6,9~19,22,23,27~31,33,34,36,39~43,45,46,54,
55,104,204,301,306,307,309,310,313~317,320,403
,405,406,413,415~417,420~422,424,427~429,432,
501,502,701,901~905,907~909
..2 CS105K1603X7R CERAMIC 1uF/16V 10% 0603 X7R 12 C57,101~103,201~203,503~505,512,513
..2 CS150J5003NPO CERAMIC 15pF/50V 5% 0603 NPO 4 C508~511
..2 CS200J5003NPO CERAMIC 20pF/50V 5% 0603 NPO 2 C401,402
..2 CS220J5003NPO CERAMIC 22pF/50V 5% 0603 NPO 2 C20,21
..2 CS221J5003NPO CERAMIC 220pF/50V 5% 0603 NPO 2 C426,703
..2 CS272K5003X7R CERAMIC 2.7nF/50V 10% 0603 X7R 1 C305
..2 CS300J5003NPO CERAMIC 30pF/50V 5% 0603 NPO 2 C318,319
..2 CS330J5003NPO CERAMIC 33pF/50V 5% 0603 NPO 3 C423,425,702
..2 CS471J5003NPO CERAMIC 470pF/50V 5% 0603 NPO 2 C506,507
..2 CS681J5003NPO CERAMIC 680pF/50V 5% 0603 NPO 1 C311
..2 CS682K5003X7R CERAMIC 6.8 nF/50V 10% 0603 X7R 1 C304
..2 DB005 Diode W005 1 D901
..2 DIEN1N4004SM Diode Power 1N4003 2 D902,903
..2 DIEN1N4148WSM Diode SMD 1 D501
..2 DISR26 SCHOTTKY BARRIER RECTIFIER 1 DZ902
..2 EC10650T Capacitor Electrolytic 10uF/50V 5*11mm 5 EC4~6,310,514
..2 EC10716T Capacitor Electrolytic 100uF/16V 5*11mm 11 EC2,301~303,306,308,311,312,405,906,907
..2 EC22450T Capacitor Electrolytic 0.22uF/50V 5*11mm 1 EC305
..2 EC22625T Capacitor Electrolytic 22uF/25V 5*11mm 2 EC501,502
..2 EC22716T Capacitor Electrolytic 220uF/16V 6.3*11mm 1 EC1
..2 EC22716TS Capacitor Electrolytic 220uF/16V 8*5mm 1 EC404
..2 EC22825 Capacitor Electrolytic 2200uF/25V 2 EC901,904
..2 EC33550TS Capacitor Electrolytic 3.3uF/50V 4*5mm 1 EC304
..2 EC33725TLE Capacitor Electrolytic low ESR 330uF/25V 8*12mm 2 EC902,905
..2 EC47616T Capacitor Electrolytic 47uF/16V 5*11mm 9 EC3,101~103,201~203,402,403
..2 EC47716T Capacitor Electrolytic 470uF/16V 8*12mm 1 EC401
..2 EC47825 Capacitor Electrolytic 4700uF/25V 16*32mm 1 EC903
..2 FCN2S1001601 FCN Dual Touch 180° Pitch=1.0mm 16P 1 FCN301
..2 FCN2S1003001 FCN Dual Touch 180 ° Pitch 1.0mm 1 FCN401
..2 FSMSMD110 Fuse PTC FSMSMD110 8V/1.1A SMD 1 FS401
..2 IC74HC08DT IC 74HC08DT 2 IC6,7
..2 IC74LVC2G08DP IC 74LVC2G08DP 1 IC701
..2 ICAIC809N46PU IC AIC809N46PU 1 IC403
..2 ICAP1501K5L IC AP1501K5L 1 IC901
..2 ICAP1534SG IC AP1534SG 1 IC902
..2 ICAP7165SPG IC AP7165-SPG-13 1 IC5
..2 ICBA033FP IC BA033FP 1 IC903
..2 ICBA5968FP IC BA5968FP 1 IC301
..2 ICBU9543KV IC BU9643KV 1 IC303
..2 ICDA1191F IC DA1191F 1 IC501
