Numark MP103 USB User Manual

..2 ICDRV602 IC DRV602 3 IC101,201,502
..2 ICDSPB56724AG IC DSPB56724AG 1 IC2
..2 ICM12L64164A-7T IC M12L64164A-7T 1 IC8
..2 ICSN74LV373APWR IC SN74LV373APWR 2 IC3,4
..2 ICTC7W14F IC TC7W14F 3 IC402,404,405
..2 ICYH2K09C01M IC YH2K09C01M 1 U402
..2 ICYH2K256 IC YH2K256 (TMP86FS49AFG+Program) 1 IC401
...3 ICTMP86FS49AFG IC TMP86FS49AFG blank 1 -
..2 ICYHFRC178 IC YHFRC178 (A25L080M-F+Program) 1 IC1
...3 ICA25L080M-F IC A25L080M-F/W25Q80BVSSIG 8M bit serial flash 1 -
..2 JKLX-1601H-3 XLR Base 90° 2 JK101,201
..2 MT0101802 SIGNAL PLATE 1 (JK501)
..2 MT0101807 EARTHER METAL 1 (JK701)
..2 MT1301803 Xlrthed Metal Plate 2 (JK101,201)
..2 PC10C030 MAIN PCB 2 Layer FR-4 1.6T 169X198mm 1 -
..2 RJ102A-09 AUDIO SOCKET 1 JK501
..2 RJ1081 1PIN RCA JACK 1 JK701
..2 RS000010J03 RESISTOR 0Ω 5% SMD 0603 18
R13~15,19,27~29,42,53,63,82,107,207,303,326,33
1~333
..2 RS001010F03 RESISTOR 10Ω 1% SMD 0603 1 R89
..2 RS001410F03 RESISTOR 14Ω 1% SMD 0603 1 R328
..2 RS001K10F03 RESISTOR 1K 1% SMD 0603 5 R78,91,315,327,442
..2 RS001M10F03 RESISTOR 1M 1% SMD 0603 4 R62,330,411,437
..2 RS002010F03 RESISTOR 20Ω 1% SMD 0603 1 R334
..2 RS002210F03 RESISTOR 22Ω 1% SMD 0603 1 R329
..2 RS002710F03 RESISTOR 27Ω 1% SMD 0603 2 R403,404
..2 RS002K10F03 RESISTOR 2K 1% SMD 0603 1 R79
..2 RS004710F03 RESISTOR 47Ω 1% SMD 0603 1 R704
..2 RS007510F03 RESISTOR 75Ω 1% SMD 0603 4 R105,106,205,206
..2 RS008210F03 RESISTOR 82Ω 1% SMD 0603 1 R703
..2 RS010010F03 RESISTOR 100Ω 1% SMD 0603 51
R1,9,10,12,16~18,20~22,24~26,33~35,38~41,43~5
2,54~56,70,72,75,77,83,323~325,409,412,501~505
,512,513,702
..2 RS010K10F03 RESISTOR 10K 1% SMD 0603 57
R2,3,5~8,36,37,57,59~61,65~67,69,71,73,74,76,84
~87,102,104,202,204,302,309~311,407,408,410,41
3,419,423~428,430~436,445~449,701,901
..2 RS015K10F03 RESISTOR 15K 1% SMD 0603 2 R405,406
..2 RS01K310F03 RESISTOR 1.3K 1% SMD 0603 1 R903
..2 RS01K510F03 RESISTOR 1.5K 1% SMD 0603 2 R103,203
..2 RS020K10F03 RESISTOR 20K 1% SMD 0603 2 R101,201
..2 RS022K10F03 RESISTOR 22K 1% SMD 0603 5 R313,316~319
..2 RS02K210F03 RESISTOR 2.2K 1% SMD 0603 1 R304
..2 RS02K710F03 RESISTOR 2.7K 1% SMD 0603 1 R301
..2 RS033010F03 RESISTOR 330Ω 1% SMD 0603 1 R4
..2 RS033K10F03 RESISTOR 33K 1% SMD 0603 2 R320,321
..2 RS036K10F03 RESISTOR 36K 1% SMD 0603 2 R507,508
..2 RS039K10F03 RESISTOR 39K 1% SMD 0603 2 R506,509
..2 RS03K310F03 RESISTOR 3.3K 1% SMD 0603 1 R305
..2 RS047010F03 RESISTOR 470Ω 1% SMD 0603 1 R322
..2 RS04K710F03 RESISTOR 4.7K 1% SMD 0603 4 R90,420~422
..2 RS04R710J03 RESISTOR 4.7Ω 5% SMD 0603 2 R306,307
..2 RS056010F03 RESISTOR 560Ω 1% SMD 0603 1 R909
..2 RS05K610F03 RESISTOR 5.6K 1% SMD 0603 2 R314,905
..2 RS068K10F03 RESISTOR 68K 1% SMD 0603 2 R510,511
..2 RS100K10F03 RESISTOR 100K 1% SMD 0603 3 R64,312,904
..2 RS1K0510F03 RESISTOR 1.05K 1% SMD 0603 1 R908
..2 RS5K4910F03 RESISTOR 5.49K 1% SMD 0603 1 R907
..2 RS7K1510F03 RESISTOR 7.15K 1% SMD 0603 1 R902
..2 TE10200502 5P CONNECTOR 2 (CN401,TE302)
..2 TE10200601 6P CONNECTOR 2 (TE4,301)
..2 TE11032501 Terminal 3P 2.5mm 90° 1 (TE902)
..2 TE612000801 8P CONNECTOR 1 (TE5)
