Check the installation
Belts must be tight.
Base should not move side to side more than
1” (25 mm) at belt path.
Belts and buckles must not interfere with
attachment of child restraint to base.
Vehicle belts must lay flat under vehicle belt
lock off.
It is acceptable to install with both UAS
(lower attachments) and the vehicle belt.
1 - After child is properly secured in child restraint,
press child restraint on base and listen for a
click. Pull on child restraint to verify installation.
DO NOT allow child restraint or handle to
contact the vehicle interior (side of car door or
seat in front) when installed on base.
2 - Adjust the angle of the base so the blue line
is levelled to the ground. A rolled up towel or
foam pool noodle may be used to help adjust
the amount of recline.
3 - To release the child restraint, squeeze the
carrier release button (1) located on the base
and then pull the child restraint up (2).
4 - To remove the base, lift up on the vehicle belt
lock off.
5 - Unbuckle the vehicle belt and un-route the
shoulder and lap belt from the base.
Then remove the base.
38 PIPA lite instructions

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Nuna Pipa lite and is the answer not in the manual?

Nuna Pipa lite Specifications

General IconGeneral
Weight Capacity4 to 32 lbs
Height CapacityUp to 32 inches
Weight5.3 lbs
Safety FeaturesSide impact protection
CompatibilityNuna strollers
Safety StandardsFMVSS 213
Infant InsertIncluded
CanopyUPF 50+ canopy
Harness Slots5-point harness
