Nuna Pipa Manual

BABY TREND HYBRID 3-IN-1 CAR SEAT
Type: Combination
Last date made: Current
First made: 2013
Weight limits: 22-50 lbs. with harness. At least 3 years and 30-
100 lbs. when used as highback booster; at least 4 years and 40-
100 lbs. when used as no back booster.
Harness: 5 point harness to 50 lbs. (removable)
Weight of restraint: 15 lbs.
Harness: Shoulder straps are attached to splitter plate behind restraint.
Lap straps are threaded through slots near child’s hips and run straight
across under the seat shell. The shoulder straps are attached to a
splitter plate behind seat. Pull strap end in front of seat to tighten
harness. Push button at lower front of seat and pull on shoulder straps
to loosen.
Harness Slots: There four sets of slots. Remove straps from splitter
plate, feed through front of restraint, thread through desired slots and
reattach straps to splitter plate.
Crotch Strap: Not adjustable.
Angle Adjustment: None.
Belt Path: If LATCH is not in use, leave connectors on back of restraint
(diagram 1).
Tether not in use with harness, lap-only belt or lap/shoulder
belt: Route vehicle belt through slots behind restraint (diagrams 2 & 3).
SEE PAGE 2
Important: This information sheet is not a substitute for complete manufacturer’s directions and current recall list.
SafetyBeltSafe U.S.A., P.O. Box 553, Altadena CA 91003 (310)222-6860 (800)745-SAFE ©SafetyBeltSafe U.S.A. #450 01/14
P. 1 of 2
1
2
3

Nuna Pipa Specifications

General

Product color	Red
Car seat group	0+ (0 - 13 kg; 0 - 15 months)
Side protection	Yes

Weight and Dimensions

Depth	700 mm
Width	435 mm
Height	530 mm
Weight	3950 g
