Nuna revv - LATCH System Installation Guide

20 REVV
™
instructions
21REVV
™
instructions
Side View & Top View
17 True Tension
™
Door
18 Side Impact
Protection Pod
19 Instruction Manual
Storage
20 Magnetic Buckle
Tongue Holder
21 Belt Positioner
22 Rotate Position
Button
23 Recline Position
Indicator
24 Recline Position
Window
21
23
Back View
25 Tether Cover
26 Handle
27 Tether Strap
28 Tether Strap
Adjuster
29 Tether Hook
30 Lower Anchor Storage
31 Lower Anchor
Connectors
32 Lower Anchor Belt
33 Lower Anchor
Adjuster
20
27
28
29
30
31
32
33
22
17
18
19
26
25
24
