Nuna revv User Manual

18 REVV
™
instructions
19REVV
™
instructions
Front View
1 Head Support
Button
2 Head Support
3 Head Insert
4 Shoulder Harness
Pad (x2)
5 Infant Insert (x2)
6 Hip Harness Pad (x2)
7 Crotch Pad
8 Recline Handle
9 Seat Cover
10 Chest Clip
11 Harness Strap
12 Cup Holder (x2)
13 Adjustable Harness
Buckle
14 Harness Release
Button
15 Harness Adjustment
Strap
16 Infant Insert
Wedge
Parts List
1
2
4
3
5
10
11
6
7
8
13
9
12
3
5
7
6
12
4
15
14
16

Nuna revv Specifications

General

Weight capacity	5 to 40 lbs (rear-facing); 25 to 40 lbs (forward-facing)
Orientation	Rear-facing and forward-facing
Recline positions	Multiple recline positions
Harness type	5-point harness
Type	Convertible car seat
Height Limit (Rear-Facing)	Up to 43 inches
Height Limit (Forward-Facing)	Up to 43 inches
Safety features	Energy-absorbing foam, side impact protection
Usage	Infant to toddler
