Forward Facing Installation
recommended when rear-facing is outgrown,
2 years or older (25–40 lb)
with lower anchor belt & tether
Forward Facing
with vehicle belt & tether
25
(11.3 kg)
40
(18 kg)
30
(13.6 kg)
Check Installation
Seat is in forward facing recline position.
Seat is securely installed. Hold seat just
below the belt path and move seat in all
directions. Seat should move less than 1 inch.
Tether is properly used and
attached to vehicle tether anchor.
2
1
Forward Facing Setup
1
- Rotate the seat forward facing. Push or pull on seat to make sure the seat is LOCKED.
2 - Select desired forward facing recline position 1–5 (RED) (p.32).
If you are using a lap belt only, you MUST use the seat in recline 5.
ALWAYS use the shoulder, hip, and crotch pads. Use infant insert with infants 5–11 lb
(2.3–5 kg) to improve the recline angle for smaller infants.
Consult pages 42–52
for complete installation
instructions.
56 REVV
™
instructions
57REVV
™
instructions
rear facing
5 4 3 2 1
1 2 3 4 5
forward facing
forward facing
5 4 3 2 1
1 2 3 4 5
rear facing

Nuna revv Specifications

General

Weight capacity	5 to 40 lbs (rear-facing); 25 to 40 lbs (forward-facing)
Orientation	Rear-facing and forward-facing
Recline positions	Multiple recline positions
Harness type	5-point harness
Type	Convertible car seat
Height Limit (Rear-Facing)	Up to 43 inches
Height Limit (Forward-Facing)	Up to 43 inches
Safety features	Energy-absorbing foam, side impact protection
Usage	Infant to toddler
