Adjustable Harness Buckle
1 - The harness buckle may be adjusted for improved comfort or fit of any child. Loosen
harness, open the chest clip and harness buckle. Lift up on the lower section of the head
support pad (1).
2 - Locate and undo 2 snap buttons on the seat back pad.
3 - Remove the harness buckle from the seat pad, and pull forward on the seat back pad.
4 - Locate the harness buckle adjustment slots in the seat shell and squeeze/pinch the
sides of the harness buckle strap together. Drop the pinched strap slightly to allow it to
pass between the positions.
5 - Slide the harness buckle strap forward or rearward (as shown) to best fit your child.
6 - Insert the harness buckle back into the correct seat pad opening. Reattach both seat
back pad snap buttons, and pull down on the lower section of the head support pad.
The infant insert (p.26) is recommended for use with infants who weigh between 5–11 lb
(2.3–5 kg). DO NOT use the insert for a child who weighs more than 11 lb.
Use the position that is closest to (but not under) your child.
1
4
2
5
3
6
24 REVV
instructions
25REVV
instructions

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Nuna revv and is the answer not in the manual?

Nuna revv Specifications

General IconGeneral
Weight capacity5 to 40 lbs (rear-facing); 25 to 40 lbs (forward-facing)
OrientationRear-facing and forward-facing
Recline positionsMultiple recline positions
Harness type5-point harness
TypeConvertible car seat
Height Limit (Rear-Facing)Up to 43 inches
Height Limit (Forward-Facing)Up to 43 inches
Safety featuresEnergy-absorbing foam, side impact protection
UsageInfant to toddler
