Nuna revv User Manual

3 - Remove slack from shoulder straps and waist belt by pulling up on shoulder straps (1).
Pull harness adjustment strap (2) to tighten. Harness should fit snugly on child's shoulders
and thighs; it is snug if you cannot pinch a fold in the strap horizontally.
Fasten and position chest clip (p.22) level with child’s armpits (3).
A snug strap should not allow any slack. It lies in a relatively straight line without
sagging. It does not press on the child's flesh or push the child's body into an unnatural
position.
3
2
1
60 REVV
™
instructions
61REVV
™
instructions
3

Nuna revv Specifications

General

Weight capacity	5 to 40 lbs (rear-facing); 25 to 40 lbs (forward-facing)
Orientation	Rear-facing and forward-facing
Recline positions	Multiple recline positions
Harness type	5-point harness
Type	Convertible car seat
Height Limit (Rear-Facing)	Up to 43 inches
Height Limit (Forward-Facing)	Up to 43 inches
Safety features	Energy-absorbing foam, side impact protection
Usage	Infant to toddler
