Softgoods Removal (cont.)
Seat Cover
1 - Move the head support to the lowest position.
2 - Undo seat pad snap buttons on the inside of the seat. Pull the harness buckle through
the seat cover and place the harness straps in the seat shell.
3 - Undo 2 side snap buttons on the seat cover, and repeat for the other side.
4 - Pull forward on the front edge of the seat cover fabric and release both fabric
stiffeners.
5 - Locate the side impact protection pod and pull down on the bottom edge. Guide the
fabric opening around and off the impact protection pod; repeat for the other side.
6 - Lift up on the seat cover and remove it from the car seat shell.
Nuna Baby Essentials, Inc. Nuna and all associated logos are trademarks.
2
3
5
4
6
1
66 REVV
™
instructions
67REVV
™
instructions
