Harness Buckle Adjustment
The harness buckle has two positions. Use the
position that is closest to (but not under) your child.
Loosen and unbuckle harness.
1 - Unsnap seat cover (1) and pull forward while
pulling harness buckle backwards through slot
in seat cover (2).
2 - Route harness buckle strap through either slot
(1 or 2) on the UAS storage door. Pull buckle
through corresponding slot in seat cover and
replace seat cover.
Cup Holder Use
3 - Pivot cup holder up and lock in use position.
4 - Push center of cup holder down to extend to
opened position.
5 - While in the opened position, pull up on the
cup holder to remove for washing.
6 - To store, collapse cup holder and pivot down.
Press to lock in position.
5
6
3
4
24
1
2
25
1
1
2
2
DO NOT place glass or metal containers or hard
or sharp objects in cup holder. In a crash they
could cause serious injury.
