Leg Rest Use
The fully adjustable leg rest can be used in both
modes of the child restraint. It can be angled to
achieve proper leg support and extended for
longer legs.
1 - The leg rest MUST NOT be above the
child restraint seating surface.
To Adjust Leg Rest:
2 - Push and hold the buttons on both sides of
the leg rest. You can now angle and extend
the leg rest simultaneously.
3 - Adjust the leg rest to the desired position by
tilting to rotate the angle (1) and pulling forward
to extend for a child with longer legs (2).
Once you reach the desired position, release
the buttons. You will hear them click as they
spring back into place, locking the leg rest.
If the buttons do not spring back right away,
gently tilt the leg rest until it locks into place.
Angle must be locked before extension can
be locked.
2
1
2
3
