Nuova Simonelli MicoBar - Page 69

Fig. 46
Fig. 46
Fig. 47
1
2
Fig. 48
Fig. 49
Fig. 45
67
EN
•Useasmallbrushtocleananydepositsorcoffee
residues off the piston and the delivery unit site
or any other areas soiled with coffee.
9.9 CLEANING THE
GASKET
NOTA: Follow the instructions applied on the label on
the inside of the front door too.
•Setthemachinetothe“O”energylevel.
9.10 CLEANING THE MILK
FOAMER
•Insertthekeyinthelock.
•TurntheFrontpanelopeningkeycounter-clock-
wise.
•OpentheFrontpanel.
IMPORTANT: Proceed with caution
•Disconnectallthetubesattachedtoit.
•Disassemblethemilk foamerandwash itcare-
fully.
NOTE: If the pause between one cappuccino and
another is over one hour long, it is advisable
to wash the milk foamer by fishing the milk
suction tube in hot water rather than in milk.
•To reassemble proceed inversely, attaching the
milk foamer tubes properly.
NOTE: To make the reassembling procedure easier,
an explanatory label has been attached to
the front door.
•Clean the drop collector (see paragraph THE
DROP COLLECTING TRAY GRID).
•Extractthewholedeliveryunitincludingthemilk
foamer, pulling it towards you.
•Extractthemilkfoamerfromthedeliverygroupby
sliding it upwards.
