Nuova MICROBAR - KEYBOARD DESCRIPTION (Standard configuration)

32
LEGENDA
1 1 Espresso key
2 2 Espressos key
3 1 Coffee key
4 2 Coffees key
5 Decaffeinated coffee key
6 1 Caffe Creme key (Coffee version)
6 1 Caffelatte key (Cappuccino version)
7 Hot water key
8 Steam key
9 LCD display
LEGENDA
1 Ground coffee conveyor
2 Coffee bean holder
3 Coffee grinder adjusting screw
4 Delivery unit
5 Water collecting tray
6 Coffee grounds drawer
7 Milk Foamer (Cappuccino version only)
8 Milk Foamer air regulator (Cappuccino version only)
9 Door key
10 Door microswitch
Fig. 2
Fig. 3
1
1
8
3
5
7
2
9
4
6
8
2
3
4
5
6
7
9
10
1.1 KEYBOARD
DESCRIPTION
(Standard configuration)
1.2 MICROBAR INTERNAL DESCRIPTION
ENGLISH
