NUVE NF200 - Technical Specifications; Technical Specifications Table; Accessories for NF200

5
SECTION 2 – TECHNICAL SPECIFICATIONS
2.1. TECHNICAL SPECIFICATIONS TABLE
Technical Specifications
NF 200
Maximum speed
5.000 rpm
Maximum RCF
2.822xg
Tube capacity
12 x 15 ml
Control system
Programmable Microprocessor Control System
Speed set range
1.000-5.000 rpm
Speed set step
10 rpm
Timer set range
1-99 min. and hold position
Timer set step
1 minute
Motor
Induction Motor
Power Supply
230 V, 50/60 Hz
Power Consumption
150 W
External Dimensions (WxDxH)
mm.
280x360x260
Packet Dimensions (WxDxH)
mm.
350x420x460
Net / Packed weight (kg)
12/16
2.2. ACCESSORIES FOR NF200
G 03 012
Adaptor for 1.5/2 ml tubes, max tube dia 11 mm
G 03 014
Adaptor for 7 ml vacuumed/ non vacuumed tubes, max tube dia 13 mm
G0 3 015
Adaptor for 5 ml vacuumed/ non vacuumed tubes, max tube dia 13 mm
