Air Filter Assembly
The OxyPure
®
comes with four different preassembled filters inside the unit (see
diagram above). Each filter is labeled with a number. Match these with the slot numbers
when installing the filters. When the filters require cleaning, please refer to Cleaning &
Maintenance.
ASSEMBLY
Open Close
Access to Filters
Stainless Steel
Pre-Filter
Bio-Guard
®
Filter 1 Ozone Emission
Removal Filter
4
3
2
1
4321
Bio-Guard
®
Filter 2
1
2
3
4
Before Use:
1. Make sure the OxyPure is unplugged. Open the Filter
Slot Cover on the back to expose the lters.
2. Remove all tape and pull the lters from their slots using
the tabs or handles.
3. Remove the plastic wrapping from the Stainless Steel
Pre-lter and the Ozone Emission Removal Filter.
(Bio-Guard
®
lters are not wrapped.)
4. Fully reinsert the lters into the Oxypure and close
the Filter Slot Cover.
5. Remove the sticker from the control panel.
