8000 BTU/HR. UNIT CHARACTERISTICS
Model
N360816GXXX N360826GXXX N360846GXXX
Dimensional Data
Height 36” / 914.4 mm
Width 11.5” / 292.1 mm
Depth 14” / 355.6 mm
Unit Weight 106 lbs / 48 kg` 106 lbs / 48 kg 114 lbs / 52 kg
Unit Protection Rating Type 12/4/4X/3R
Cooling Data
Refrigerant R134a
Refrigerant Charge 27 oz. 32 oz. 33 oz.
Cooling Capacity at 95 F Enclosure 95 F
Ambient (BTU/Hr.)
6248/6739 6515/6855 6448/6716
Cooling Capacity at Max Conditions
(BTU/Hr.)
7074/7754 7444/7955 7311/7940
Maximum Ambient Temp 131 F / 55 C
Minimum Ambient Temp -40 F / -40 C
Enclosure Airow 245/258 CFM
External Airow 353/396 CFM 347/382 CFM 347/382 CFM
Condensate Management Hose discharge / Optional powered C/E
Heating Data
Capacity 1300 W
Electrical Data
Rated Voltage (50/60 Hz) 115 V 230 V 400/460 V 3 phase
Rated Frequency 50 / 60 Hz
Voltage Range +/- 10% of rated
Cooling Amps at Max Conditions 9.9/11.6 5.1/6.6 2.3/2.5
Heating Amps 12.2 6.2 1.9
Compressor RLA / LRA 5.4/38 3.7/19.0 2.0/16.0
Evaporator Fan RLA .78/.93 .39/.53 .39/.53
Condenser Fan RLA 1.2/1.5 .39/.53 .39/.53
