Nvidia BlueField-2 BF2500 User Manual

33
Side B
Pin# Pin Name Pin Definition Description
B1 12V POWER 12V power
B2 12V POWER 12V power
B3 12V POWER 12V power
B4 GND GND Ground
B5 SMCLK I/O SMBUS_SCL - connected to BlueField IPU
B6 SMDAT I/O SMBUS_SDA - connected to BlueField IPU
B7 GND GND Ground
B8 3.3V POWER 3.3V power
B9 TRST# NC Not connected
B10 3.3V_AUX POWER 3.3V auxilary power
B11 WAKE NC Not connected, option connect to NIC_GPIO[13]
Key
B12 RSVD NC Not connected, option for SER_DI
B13 GND GND Ground

Nvidia BlueField-2 BF2500 Specifications

General

Processor	ARM Cortex-A72
Memory	16 GB DDR4
Network Interfaces	2 x 100GbE
PCIe Interface	PCIe 4.0 x16
Product Type	DPU (Data Processing Unit)
Interface Type	Ethernet
Ethernet Ports	2
Maximum power consumption	75W
PCIe Lanes	16
Operating Temperature	0°C to 55°C
Storage Acceleration	Yes
Virtualization Support	Yes
Security Features	Secure Boot
