Nvidia BlueField-2 BF2500 User Manual

38
Pin# Pin Name Pin Definition Description
B78 PETP15 IN SoC RX
B79 PETN15 IN SoC RX
B80 GND GND Ground
B81 PRESNT2# OUT X16 PCIe card detection, connected to PRESNT1#
B82 RSVD NC Not connected
Power Sequencing
The BF2500 Controller Card requires the 12V ATX PCIe power to come up prior or at the same time to the +12V at the PCIe edge connector.
NC-SI Management Interface
The below table lists the NCSI Management Interface pins description. For further details, please refer toNC-SI Management Interface
.

Nvidia BlueField-2 BF2500 Specifications

General

Processor	ARM Cortex-A72
Memory	16 GB DDR4
Network Interfaces	2 x 100GbE
PCIe Interface	PCIe 4.0 x16
Product Type	DPU (Data Processing Unit)
Interface Type	Ethernet
Ethernet Ports	2
Maximum power consumption	75W
PCIe Lanes	16
Operating Temperature	0°C to 55°C
Storage Acceleration	Yes
Virtualization Support	Yes
Security Features	Secure Boot
