Nvidia BlueField-2 BF2500 User Manual

46
External Power Supply Interfaces
The below table lists the External Power Supply pins of the external power supply interface on the BF2500 Controller card. For further details, please refer
toExternal PCIe Power Supply Interfaces
.
Pin # Signal Name Description
1 12V ATX supplied 12V
2 12V ATX supplied 12V
3 12V ATX supplied 12V
4 GND Power Return
5 Sense Indicates proper connectivity
6 GND Power Return
The mechanical pinout of the 6-pin external +12V power connector is shown below. This +12V connector is sometimes referred to as EPS-12V. Care
should be taken to ensure the power is applied to the correct pins as some 6-pin ATX type connector can have different pinouts.


Nvidia BlueField-2 BF2500 Specifications

General

Processor	ARM Cortex-A72
Memory	16 GB DDR4
Network Interfaces	2 x 100GbE
PCIe Interface	PCIe 4.0 x16
Product Type	DPU (Data Processing Unit)
Interface Type	Ethernet
Ethernet Ports	2
Maximum power consumption	75W
PCIe Lanes	16
Operating Temperature	0°C to 55°C
Storage Acceleration	Yes
Virtualization Support	Yes
Security Features	Secure Boot
