29
4. If the installation script has performed a firmware update on your network adapter,
complete the step relevant to your adapter card type to load the firmware:
• ConnectX-5/ConnectX-5 Ex - perform a standard reboot
Otherwise, restart the driver by running:
/etc/init.d/openibd restart
After installation completion, information about the Mellanox OFED installation, such as prefix, kernel
version, and installation parameters can be retrieved by running the command /etc/infiniband/info.
Most of the Mellanox OFED components can be configured or reconfigured after the installation, by
modifying the relevant configuration files. See the relevant chapters in this manual for details.
The list of the modules that will be loaded automatically upon boot can be found in the /etc/infiniband/
openib.conf file.
Installation Results
• Most of MLNX_OFED packages are installed under the “/usr” directory
except for the following packages which are installed under the “/opt”
directory:
• fca and ibutils
• The kernel modules are installed under
• /lib/modules/`uname -r`/updates on SLES and Fedora
Distributions
• /lib/modules/`uname -r`/extra/mlnx-ofa_kernel on RHEL and
other Red Hat like Distributions
Software

In case your machine has an unsupported network adapter device, no firmware update
will occur and one of the
following error messages below will be printed. Please
contact your hardware vendor for help on firmware
updates.
Error message 1:
Device #1:
Device Type:
Part
Number:
Description:
x16, tall bracket
PSID:
PCI Device Name:
Base MAC:
Versions:
ConnectX-5
MCX515A
-CCAT
ConnectX®-5 EN network interface card, 100GbE single-port QSFP28, PCIe3.0
MT_2190110032
0b:00.0
0000e41d2d5cf810
Current
FW 16.22.0228
Available
N/A
Status: No matching image found
Error message 2:
The firmware for this
device is not distributed inside Mellanox driver: 0000:01:00.0 (PSID:
IBM2150110033)
To obtain firmware for this device, please contact your HW vendor.
