Specifications
MCX512A-ACAT Specifications
Physical
Size: 2.71 in. x 5.6 in. (68.90mm x 142.24 mm) – low profile
Connector: Dual SFP28 Ethernet (copper and optical)
Protocol Support
Ethernet: 25GBASE-CR/CR-S, 25GBASE-SR, 25GBASE-LR, 25G Ethernet
Consortium, 10GBASE-SR, 10GBASE-LR, 10GBASE-ER, SGMII / 1000BASE-X
Data Rate: 1/10/25 Gb/s Ethernet
PCI Express Gen3: SERDES @ 8.0GT/s, 8 lanes (2.0 and 1.1 compatible)
Power
Power Cable Type
Typical Power
(a)
Passive Cable 9.5W
Maximum Power
Passive Cable 11.8W
1.5W Active Cable 15.1W
Maximum power available through SFP28 port: 1.5W
Temperature Operational 0°C to 55°C
