Nvidia Mellanox ConnectX-5 - Airflow Specifications

57
1.5W Active Cable 22.3W
2.5W Active Cable
24.6W
Maximum power available through QSFP28 port: 5W
Temperature:
Operational
0°C to 55°C
Non-operational -40°C to 70°C
Humidity:
90% relative humidity
(b)
Altitude (Operational) 3050m
Airflow: See Airflow Specifications.
Regulatory
Safety: CB / cTUVus / CE
EMC: CE / FCC / VCCI / ICES / RCM
RoHS: RoHS-compliant
Notes: a. Typical power for ATIS traffic load.
b. For both operational and non-operational states.
Airflow Specifications
Airflow (LFM) with airflow direction from heatsink to port.
Cable Type
OPN
Passiv
e
Active 1.5W Active 2.5W Active 3.5W Active 5W
MCX512A-ACAT
150LFM 300LFM N/A N/A N/A
MCX515A-CCAT 300LFM 350LFM 400LFM 400LFM 950LFM
MCX516A-CCAT
350LFM 500LFM 600LFM 650LFM 1300LFM
