Nvidia Mellanox ConnectX-5 - Mechanical Drawings

58

All dimensions are in millimeters. All the mechanical tolerances are +/- 0.1mm.

For the 3D Model of the card, please refer to 3D Models at http://www.mellanox.com/page/
3d_models.
Board Mechanical Drawing and Dimensions
Mechanical Drawing of a Dual-Port x16 Card
Mechanical Drawing of a Dual-Port x8 Card
