3.3. External Connectors
O
R
P
S
Q
T
DC Input connector
Air Intake fi lter
Sensor connector #1
Sensor connector #2
22mm gas output connector
Gas supply input
O
P
Q
R
S
T
Figure 02
Battery door
Relieve Flapper
Air/O
2
Exhaust Port
