e700 User Manual
Figure 11.a - SIMV waveform w/o pressure support
O
2
% (100% or 60%) 100 100 100
Mv max (2 -40 L) 30 30 30
Mv min (0.5 – 35 L) 0.5 0.5 0.5
P max. 10 -80 cmH
2
O 25 25 30
P min.
0-20 cmH
2
O
(during I time only)
3 3 3
Manual
Refer to Manual
and I-Hold section
ready ready ready
* Ti may be limited below its range depending on set I:E ratio and rate.
