O2 WAP5884 User Manual

5
1-5 Familiar with your new wireless repeater
Interface Descriptions
Item
Item Name
Description
A
Mode switch
You can switch the operation mode by this switch,
this Range Extender supports 3 modes, include AP
mode, Repeater mode and Client mode.
B
LAN port
One 10/100Mbps Ethernet LAN Port with
Auto-MDI/MDI-X. Connecting to computer, switch
or other device for network.
C
WPS / Reset button
This button support 2 functions:
1. One click to start WPS function
2. Hold the button 10 seconds to reset all the values
to the factory default.
A
B
C

O2 WAP5884 Specifications

General

Brand	O2
Model	WAP5884
Category	Extender
Language	English
