44-11/16
[1135]
44-5/16
[1126]
3-15/16
[100]
40-3/4
[1035]
28-13/32
[722]
40
[1016]
WALL OPENING
BOTTLE FILLER
JUNCTION BOX
(SEE NOTE 4)
4-5/16
[110]
39-1/2
[1003]
38-3/4
[984]
WALL OPENING
1-19/32
[41]
CHILLER
JUNCTION BOX
3/8 O.D WATER INLET
1-1/2 OR 1-1/4 IPS WASTE
STUB OUT 2[51]
ELECTRIC EYES
(IF APPLICABLE)
19-3/4
[502]
VERSAFILTER III
34-9/16
[878]
TO ORIFICE
28-3/4
STUB OUT
[730]
3-3/32
[78]
TO ORIFICE
27
[690]
11-5/16
[287]
WALL OPENING
(ALLOW FOR ADDITIONAL DEPTH
FOR WATER AND WASTE LINES)
1/2
[13]
2
[51]
WALL LINE
FRAME ASSY
FURNISHED
5/16 [8] DIA. MOUNTING
HOLES 8 EACH SIDE
FACE OF FRAME MUST
BE FLUSH WITH FINISHED
WALL LINE
2
[51]
1-1/2 OR 1-1/4
IPS WASTE
STUB OUT
TO BUBBLER
VALVE
1/4 O.D. TUBE
CHILLER
WATER INLET
21-9/16
[548]
FRAME ASSY
FURNISHED
FRAME ASSYSOLENOID VALVE
AND EE SENSOR
ELECTRICAL
CONNECTION
2
[686]
19
[483]
DISTANCE
FROM WALL
2-5/32
[55]
6-7/16
[164]
ELECTRICAL
CONNECTIONS
5/16 [8] DIA. MOUNTING HOLES
8 TOP AND 8 BOTTOM
3-1/16
[78]
8-1/16
[205]
1-1/2
[38]
ELECTRICAL
CONNECTIONS
5-11/32
[136]
3-1/2
[89]
9-7/8
[251]
ELECTRICAL OUTLET
OPTIMUM LOCATION
(SEE NOTE 4)
13
[330]
44-11/16
[1135]
26-23/32
BOTTLE FILLER
STUB OUT
[679]
FLOW REGULATOR
ACCESS THROUGH
HOLE IN BUTTON
(MECH. VERSION
ONLY)
7/8 [22] DIA. HOLE
FOR ELECTRICAL
CONNECTION
NOTES:
RECOMMENDED ADULT HEIGHT INSTALLATION SHOWN. ADJUST VERTICAL
DIMENSIONS AS REQUIRED TO COMPLY WITH FEDERAL, STATE AND LOCAL
CODES.
STOP VALVE, TRAP, PIPE CONNECTOR TO WASTE LINE NOT PROVIDED. SHORT
RADIUS TRAP REQUIRED.
ALL DIMENSIONS ARE IN INCHES. DIMENSIONS IN [ ] ARE IN MILLIMETERS.
115V GROUNDED NORTH AMERICAN DUPLEX RECEPTACLE REQUIRED. THIS
DRINKING WATER COOLER IS INTENDED TO BE CONNECTED TO A 20A
MINIMUM GROUND FAULT CIRCUIT INTERRUPTING (GFCI) DEVICE TO MEET
UL REQUIREMENTS.
FILTER INSTALLATION LOCATIONS WILL VARY BY MODEL.
4 .
5 .
1 .
2 .
3 .
(IF APPLICABLE)
(IF APPLICABLE)
APPROX. LOCATION
6
OASIS AQUA POINTE® ELECTRONIC BOTTLE FILLER MODELS MEBF, M8EBF, M12EBF, MEBFEE,
M8EBFEE, M12EBFEE
