Location of Controls
1. TFT color display
2. Infrared remote sensor
3. 3.5 mm audio out socket –
Connect external powered
speakers with 3.5 mm plug or
RCA adaptor with 3.5mm plug
4. 3.5mm antenna input socket
5. Optical Out- Digital optical
output connection
6. DC IN socket- Connect with
the AC adaptor supplied in the
package
7. Power On/OFF switch
- 1 -
