- 12 -
6) If the connection is successful “Association Complete” will be
displayed briefly.
To repeat the above procedure, or if the Configure Network wizard
does not automatically start, the network can be connected by using
the Configuration mode.
1) Press the Home button to go to My Favorite mode.
2) Using the Tune/Select knob navigate to and select configuration
3) Select Network
There are three different options to connect to the network from the
Configuration mode:
1) Repeat steps 2) through 5) above.
2) Select Add AP (WPS button) – Press WPS button on your router
within 2 minutes to complete the connection.
3) Select Add AP (Smart Config) – Download APP ESPTouch (it
configures ESP32 devices such as the WR-50CD) and install on a
smart phone, tablet or other device that can use APPs. Start the
APP to complete the connection.
Connection status is displayed in the top left hand corner of the LCD
with the Wi-Fi symbol and signal strength bars ( ).
For best Wi-Fi performance, limit “drop outs” (interruptions) the Wi-Fi
Channels must be set according to the location of the Radio Tuner e.g.
China, USA, Europe. The factory default is China.
To set the correct location, select Configuration, Network, Wi-Fi
Channels and select the correct option.
Network Setup
