156
NUMERIC DISPLAYS (cont'd): Range: Resolution:
Time to Desaturate 23:50 max to 0:00 hr:min* 1 minute
(* starting 10 min. after the dive)
Temperature 0 to 140°F (-9 to 60°C) 1°
Tank Pressure 0 to 5000 PSI (345 BAR) 5 PSI (1 BAR)
Time of Day 0:00:00 to 23:59:59 hr:min 1 minute
FREE Countdown Timer 59:59 to 0:00 min:sec 1 second
Out of Range (- - -) => 330/399 FT (100/120 M)
Violation Countdown Timer 23:50 to 0:00 hr:min (after violation)
BAR GRAPHS
Tissue Loading Bar Graph: segments
No Decompression zone 1 to 7
Decompression zone 8 (all)
Oxygen (O2) Bar Graph: segments
Normal zone 1 to 4
Danger zone 5 (all)
Variable Ascent Rate Indicator:
Deeper than 60 FT (18 M) 60 FT (18 M) & Shallower
Segments Ascent Rate = Segments Ascent Rate =
Displayed FPM MPM Displayed FPM MPM
0 0-20 0-6 0 0-10 0-3
1 21-30 6.1-9 1 11-15 3.1-4.5
2 31-40 9.1-12 2 16-20 4.6-6
3 41-50 12.1-15 3 21-25 6.1-7.5
4 51-60 15.1-18 4 26-30 7.6-9
5 60 + 18 + 5 30 + 9 +
SPECIFICATIONS (CONTINUED)
