BA_OTE 3+4_Endkunde_EN_V03_20170726.docx Page 33 of 52
10 Heat distribution / heat manager
The temperature image of the heat distributor gives information on the current system
flow temperature.
System temperature call up:
1. Press the adjustment knob in the main
display > the main menu appears
2. Select the desired menu by turning the
adjustment knob and confirm by pressing
the knob. The temperature image for the
selected menu appears
3. The current values are displayed in the
temperature image
see temperature images; select the
menu by pressing the adjustment knob.
4. By turning the adjustment knob, select
Setpoint and actual values in the sub-
menu and confirm this by pressing the
knob.
5. Call up data and by repeated pressing of
the ESC – knob you return to the main
display.
11 Cascade manager
The cascade manager is necessary when several heat pumps are used in a heating system
(cascading). If required, please contact the OCHSNER customer service or your nearest
OCHSNER system partner
(TPO) with buffer/ header tank
(TWV) without buffer tank and 1xheating circuit
Setpoint and actual values
