BA_OTE 3+4_Endkunde_EN_V03_20170726.docx Page 9 of 52
5.3 Operation selection heating circuit
The following modes of operation can be set:
Mode of operation Description
Heating circuit OFF (frost protection function still active)
1: Automatic
Automatic control according to the time program set, auto-
matic switch-over HEATING/COOLING (recommended)
Without timer program, the heater control always controls to
room temperature set value.
Without timer program, the heater control always controls to
set-back room temperature set value.
Heating to a permanent set flow value (07-009)
Heating curve not active
8: Manual cooling mode
Heating to a permanent set flow value (07-009)
Heating curve not active
Settings procedure:
1. Press the adjustment button in the main
display > the main menu appears
2. Select the Heating Circuit by turning the ad-
justment knob and confirm by pressing the
knob.
3. In heating circuit temperature image, select
the sub-menu by pressing the adjustment
knob.
4. Confirm the operation mode by pressing the
adjustment knob
5. Confirm the operation mode by pressing the
adjustment knob
6. Set the operation mode by turning the ad-
justment knob and store this by pressing.
